Construction
4 layer co- extruded composite material made from FR reinforced Fiber Glass DimondScrim withOne side highly reflective Metalized Polyester Film& Other Side PE Coating
SPECIFICATION:
- 12MIC METPET – INSULATION GRADE
- 9 GSM DIMOND SHAPE FIBER GLASS SCRIM RAINFORCEMENT
- PE FILM
Typical Physical Property
Property |
Test Method |
Unit |
Results |
Grammage |
ISO 536 |
g/ sqm |
47-52 (+/-5%) |
Tensile – MD and CD |
ASTM D 828 |
N/25mm |
90 - 125 |
Burst Strength |
ASTM D 774 |
N/25mm |
100 |
Water Vapour Transmission |
ASTM F 1249 |
N |
<1 |
Temperature Resistant |
ASTM C 1263 -29~66 °C |
- |
Remains Flexible No Delamination |
Emissivity |
ASTM E408 |
% |
0.03-0.05 |
Reflectivity |
ASTM E408 |
% |
95-97% |
Working Tempreture |
Celsius |
-50 to 110°C |
Our SunPro® MFPEMETPET PE Scrim insulation are mainly used under roof decking, under attic rafters, over existing attic insulation, in floors, walls and crawl spaces, and in industrial and commercial buildings to block radiant heat coming into house through the roof during the summer and retain indoor heat generated during the winter. Also used as a moisture vapor barrier in air conditioning ductworks and cold rooms. It is used as packing material for big machine to prevent moisture and radiant heat to contact machine.
Product Benefits
- Eco-friendly, environment friendly and radiant barrier.
- Reflective Metpet Film stops up to 97% of radiant heat transfer Which improves the performance of the insulating material.
- Lightweight and easy handling and low cost.
- Never use chemical bonding materials.
- For heavier basic weight based on order are also available.
- Different lengths and basic weight are available.
Remarks
- Above data are typical results and not the guaranteed performance.
- Tolerance: Weight and Thickness: ±10%; Width: ±2mm; Length: ±0.5%.
- The products should be stored at room temperature away from wet and heat source.
- Please do trial-application and make sure the product can serve the specific application before actually put it to use.
Packaging Details:
- Core ID: 76mm (3inch) Standard
- length: 1000 mtrs, Other lengths available On request
- Thickness tolerance: +/-7% Maximum
- 1220mm to 1520mm
